Unitized aluminum curtain wall refers to the frame-supported glass curtain wall that is installed and constructed on site. The aluminum alloy frame, glass, pads, thermal insulation materials, shock absorption and waterproof materials, and decorative fabrics are assembled into a curtain wall unit with additional connectors in the factory in advance, and then transported to the construction site by a special transport vehicle. The glass curtain wall is hoisted and assembled on site and directly connected to the building structure.
Product Name |
Unitized aluminum curtain wall |
Material |
Aluminum alloy 6063, 6061, 6005, 6463, 7075, etc. |
Temper |
T3-T8 |
Category |
Open |
Thickness |
1.5mm, 2mm, 3mm, 4mm, 5mm, 6mm, etc. |
Minimum Size |
709mm*790mm |
Maximum Size |
1.5M*10M |
Glass Thickness |
6mm-40mm, customized |
Compressive Strength |
Powerful |
Surface Treatment |
Anodizing, powder coating, electrophoresis, wood grain, etc. |
Deep Processing |
Drilling, bending, welding, aluminium profile fabrication, precise cutting, etc. |
Application |
Indoor and outdoor decoration, construction, decoration engineering, etc. |
Standard |
ASTM, AISI, JIS, ISO, EN, BS, GB, etc. |
Export |
United States, Australia, Brazil, Canada, Peru, Iran, Italy, India, United Kingdom, Arabia, etc. |
Payment Method |
T/T, Western Union, L/C, etc. |
Package |
Standard seaworthy export packing: wooden pallet with plastic protection or as customer's request. |
Pricing Term |
EXW,FOB,CIF,CFR,CNF etc. |
1. The height of the unitized aluminum curtain wall is the height of the floor, which can be directly hung on the embedded parts of the floor, which is easy to install.
2. In the factory, glass, aluminum plate, stone and other surface materials are assembled into a unit plate to promote factory processing.
3. The unit plate is processed in the factory, which is conducive to quality inspection and improves the quality of the curtain wall.
4. The embedded parts and processing dimensions of the unitized aluminum curtain wall require extremely high precision. Because of the high dimensional accuracy, the cost control such as the utilization rate of the profiles is greatly improved.
5. The installation of the unit plate can be completely completed in the building, saving the cost of scaffolding or spider plants.
6. The sealing strip has strong aging resistance.
